3
Illustrated
Parts List
To order
replacement parts,
call the Customer
Service Line at
1-800-800-7310
or visit
www.mtdproducts.com
NOTE: Tractor features vary by model. NOT all parts listed above and pictured on the previous page are standard
equipment.
Ref.
No.
Part No. Description
1 710-0726 Screw, 5/16-12 x .750
2 710-0599 Self-tapping Screw, 1/4-20 x.5
3 710-0751 Hex Cap Screw, 1/4-20 x.62
4 746-04365 Throttle Control/Cable
5 725-1745 Ignition Key w/ plastic cover
725-1744 Ignition Key w/o plastic cover
6 731-04949 Headlight Lens
7 738-04091 Shoulder Screw,.43 x.29
8 783-04551 Hood, 1 Style
9 783-04552 Grill, 1 Style
10 783-04578 Pivot Bracket - RH
783-04577* Pivot Bracket - LH
11 783-04621 Grill Pivot Bracket
12 712-04064 Flange Lock Nut, 1/4-20
13 751-0658E Fuel Tank, Three Gallon
14 751-0603 Fuel Cap
15 710-1017 Screw, 1/4-14 x.625
16 710-0895 Self-tapping Screw, 1/4-15 x.75
17 746-1085A Choke Control Cable
18 725-04227B Ignition Switch
19 731-05522 Hood Cover, 5 Style
20 731-05005B Dash Panel
21 731-04215 Cruise Control Button
22 731-04217 Parking Brake Button
Ref.
No.
Part No. Description
23 736-0176 Flat Washer, .265 x .938 x 1.20
24 747-1196 Brake/Cruise Pivot Rod
25 629-04083A* Headlight Wire Harness
26 731-05165A Plenum
27 783-04285E RH Dash Support Plate
28 710-0607 Screw, 5/16-18 x .500
29 783-04323D LH Dash Support Plate
30 725-0963 Lamp
31 736-0270 Bell Washer,.265 x.75 x.062
32 710-1611B Screw, 5/16-18 x.75
33 725-1649 Headlight Socket
34 710-1652 Hex Index Screw, 1/4-20 x.625
35 683-04219A Bumper Assembly
36 712-04065 Flange Lock Nut, 3/8-16
37 731-05674 Cap
38 738-0143 Shoulder Bolt, 3/8-16
39 725-1752 Electric PTO Switch
40 725-04036C Systems Ind. Monitor w/Hr. Mtr.
725-04156 Systems Ind. Monitor w/ Amtr.
— 725-04403* Wire Harness (w/Hour Meter)
— 725-04404* Wire Harness (w/Hour Meter &
Electric PTO)
— 725-04411* Wire Harness (w/Ammeter)
— 777X41984 Headlight Reflective Insert
* Not Shown
