5
Illustrated
Parts List
To order
replacement parts,
call the Customer
Service Line at
1-800-800-7310
or visit
www.mtdproducts.com
NOTE: Tractor features vary by model. NOT all parts listed above and pictured on the previous page are standard
equipment.
Ref.
No.
Part No. Description
1 710-0227 Screw, #8-18 x.500
2 683-04301 Lift Shaft Assembly
3 736-0204 Washer, Flat, .344 x .62 x .033
4 736-0607 Lock Washer, 5/16
5 712-04065 Flange Lock Nut, 3/8-16
6 712-04063 Flange Lock Nut, 5/16-18
7 725-1439 Inner Seat Spring Switch
8 714-0104 Hairpin Clip
9 726-3046 Foot Pad Clips
10 716-0106A E-Ring
11 720-0311 Handle Grip
12 732-0874 Torsion Spring
13 732-1184 Extension Spring,.84 x 4.6
14 736-0242 Flat Washer
15 726-0278 Insulator Boss Plate
16 736-0300 Flat Washer, .406 x .875 x .059
17 710-0599 Screw, 1/4-20 x.500
18 738-0138A Hex Cap Screw, 5/16-18 x.62
19 738-0380 Shoulder Screw, 3/8-16
20 741-0225 Hex Flange Bearing
21 712-0271 Sems Nut 1/4-20
22 746-0968 Lift Cable, 16.16
23 747-04447 Lift Handle
24 756-1154 Roller Pulley
25 783-0678B Arm Lift
Ref.
No.
Part No. Description
26 731-1993A Cover w/ Cup Holder
27 710-0451 Carriage Bolt, 5/16-18 x.750
28 710-0604A Self-tapping Screw, 5/16-18 x.625
29 710-0895 Self-tapping Screw, 1/4-15 x.75
30 731-1990 Lift Lever Cover
31 738-0296 Shoulder Screw,.437 x.286
32 736-3078 Flat Washer,.349 x 1.0 x.063
33 783-0677B Lift Adjustment Bracket
34 783-04459A Fender 4 Sty Hydro w/ Flares
35 783-1489C Seat Mounting Bracket
36 720-04061 Knob, 3/8-16 x .875
37 712-04064 Flange Lock Nut, 1/4-20
38 738-04012A Shoulder Screw, 3/8-16 .625 x .145
39 757-04003A High Back Seat, Black
40 783-04081B Seat Pivot Bracket
41 725-1303 Outer Seat Spring Switch
42 710-0932 Carriage Screw 1/4-20 x 1.00
43 735-0656 RH Foot Pad
44 735-0657 LH Foot Pad
45 714-0111 Cotter Pin
46 726-0279 Insulator Plate
47 783-0209D Seat Lift Bracket
48 726-0201 Speed Clip
49 731-2618 RH Fender Flare
50 731-2619 LH Fender Flare
