Safety • Set-Up • Operation • Adjustments • Maintenance • Troubleshooting • Parts Lists • Warranty
OPERATOR’S MANUAL
IMPORTANT:
READ SAFETY RULES AND INSTRUCTIONS
CAREFULLY BEFORE OPERATING EQUIPMENT.
PRINTED IN U.S.A. MTD Products Ltd., P. O. Box 1386, KITCHENER, ONTARIO N2G
21” Self-Propelled Rotary Mower — Model Series 500
12/21/09
769-02894C

Table of Contents

Questions and Answers

  • A
    Andrea RyanAug 6, 2025
    How to fix MTD Lawn Mower engine that fails to start?
    • A
      Amanda MillerAug 6, 2025
      Several factors can cause the MTD Lawn Mower engine to fail to start. Here are a few things to check: * Ensure the blade control handle is engaged. * Verify the spark plug wire is connected to the spark plug. * Make sure the fuel tank is filled with clean, fresh gasoline. Other potential issues include a faulty spark plug (clean, adjust gap, or replace), a blocked fuel line (clean it), or engine flooding (wait a few minutes to restart, without priming). Also, check if the fuel valve is open (if equipped) and that the engine is properly choked (if equipped with a choke). For electric start models, a burnt fuse could also be the culprit (replace the fuse, referring to the Maintenance Section).
  • L
    lindahoweAug 10, 2025
    Why does my MTD YARD-MAN 12AV569Q501 Lawn Mower engine run erratic?
    • C
      Christopher RoachAug 10, 2025
      If your MTD Lawn Mower engine runs erratically, start by checking the spark plug wire to ensure it's securely connected and tightened. Also, verify that the fuel line isn't blocked and that you're using clean, fresh gasoline. A plugged gas cap vent could also be the issue, so clear the vent. Additionally, water or dirt in the fuel system can cause problems; drain the fuel tank and carburetor and refill with fresh fuel.
  • L
    Lisa PayneAug 14, 2025
    Why MTD YARD-MAN 12AV569Q501 Lawn Mower will not mulch grass?
    • L
      Lonnie WilliamsAug 14, 2025
      If your MTD Lawn Mower is not mulching grass effectively, it could be due to several reasons. Avoid mowing when the grass is wet; wait until it's drier. If the grass is excessively high, mow once at a higher cutting height, then mow again at the desired height, or try making a narrower cutting path. A dull blade can also hinder mulching, so sharpen or replace it.
  • G
    gdavisAug 19, 2025
    Why is my MTD YARD-MAN 12AV569Q501 Lawn Mower engine overheating?
    • J
      Joanna SimpsonSep 12, 2025
      If your MTD Lawn Mower engine is overheating, first check the engine oil level and fill the crankcase with the proper oil if it's low. Also, make sure that there are no restrictions in the airflow. Remove the blower housing and clean it.
  • J
    jmccarthyAug 23, 2025
    What to do if my MTD YARD-MAN 12AV569Q501 Lawn Mower has an uneven cut?
    • D
      Dennis RoseAug 23, 2025
      If your MTD Lawn Mower is producing an uneven cut, ensure that all four wheels are in the same height position. Also, check the blade. A dull blade can cause an uneven cut, so sharpen or replace it.
  • C
    Carla SmithAug 27, 2025
    Why is my MTD YARD-MAN 12AV569Q501 Lawn Mower experiencing excessive vibration?
    • M
      morrAug 27, 2025
      Excessive vibration in your MTD Lawn Mower can be caused by a loose or unbalanced cutting blade; tighten the blade and adapter. Another cause could be a bent cutting blade, in which case you should replace the blade.
  • R
    Ricky RandolphSep 1, 2025
    Why MTD Lawn Mower wheels will not propel?
    • M
      Matthew ClineSep 1, 2025
      If your MTD Lawn Mower wheels will not propel, check the belt for proper pulley installation and movement. Also, make sure that there is no debris clogging the drive operation. Clean out any debris.

Summary

Safe Operation Practices

Slope Operation Guidelines

Provides guidelines for safe mowing on slopes, including do's and don'ts.

Children Safety Precautions

Emphasizes safety precautions regarding children around the mower.

Safe Gasoline Handling

Details safe procedures for handling gasoline to prevent fire and injury.

General Service Precautions

Engine Modification Warning

Warns against engine modifications that could lead to unsafe operation.

Setup and Adjustment

Cutting Height Adjustment

Drive Control Adjustment

Operating Your Lawn Mower

Before Starting Procedures

Using Your Lawn Mower Tips

Provides tips and recommendations for effective and safe lawn mowing.

Operating Tips

Maintenance

Blade Care and Maintenance

Explains inspection, sharpening, and balancing procedures for the mower blade.

Belt Care and Replacement

Trouble Shooting

MTD YARD-MAN 12AV569Q501 Specifications

General IconGeneral
Engine Displacement159 cc
Cutting Width21 inches
Cutting Height1.25 - 3.75 inches
Cutting Positions6
Speed SettingsVariable
Mulching CapabilityYes
Bagging CapabilityYes
Side Discharge CapabilityYes
Deck MaterialSteel
Drive SystemRear Wheel Drive
Start TypePull start
Engine TypeGas
Wheel Size8 inches front / 12 inches rear
