NOTE: For painted parts, please refer to
the list of color codes below. Please add
the applicable color code, wherever
needed, to the part number to order a
replacement part. For instance, if a part
numbered 700-xxxx is painted Yard-Man
Green, the part number to order would be
700-xxxx-0665.
Yard-Man Green: 0665
Yard-Man Yellow: 0674
Powder Black: 0637
REF.
NO.
PART
NO. DESCRIPTION
1 712-0431 Flange Lock Nut, 3/8-16
2 732-0996 Compression Spring, 1.31 x 3.0
3 783-0733 Spacer Cup, 1.5 OD
4 732-0997 Compression Spring, .66 OD x 1.5
5 710-0604A Self-tapping Screw, 5/16-18 x .625
6 710-0751 Hex Cap Screw, 1/4-20 x .62
7 712-0271 Hex Sems Nut, 1/4-20
8 712-3044 Wing Nut, 1/4-20
9 725-1706 12-volt Battery, 270 CCA
10 738-1014 Shoulder Screw, .5 x 1.25, 3/8-16
11 738-1020 Shoulder Screw, .625 x .5, 7/16-20
12 736-0407 Bell Washer, .45 x 1.0 x .062
13 723-0444 Battery Strap
14 783-1031 Hitch Plate
15 725-1747 Safety Interlock Plunger Switch
16 736-0222 Lock Washer, 1/4
17 725-1426 Solenoid, 12-Volt, 100 Amp
18 710-0599 Self-tapping Screw, 1/4-20 x .5
19 712-0459 Flange Lock Nut, 7/16-20
20 683-0304 Lower Frame Assembly
21 756-0639A Engine Pulley, 3.56 OD
22 783-1003 Electric Clutch Anti-rotation bracket
23 712-3010 Hex Nut, 5/16-18
24 710-3180 Hex Cap Screw, 5/16-18 x 1.75 (Grade 5)
25 732-0978 Extension Spring, 1.2 OD x 3.638
26 710-0642 Self-tapping Screw, 1/4-20 x .750
27 736-0322 Flat Washer, .45 x 1.25 x .164
28 712-3004A Flange Lock Nut, 5/16-18
29 783-0653C Steering Support Bracket
30 683-0301 Idler Bracket Assembly (42-inch decks)
683-0297 Idler Bracket Assembly (46-inch decks)
31 738-3056 Shoulder Screw, 1/2 Diameter x 2.5
32 717-1708 Electric PTO Clutch
33 738--0785 Shoulder Spacer, 1.38 x .445 x .36
34 736-0171 Lock Washer, 7/16
35 710-3157 Hex Cap Screw, 7/16-20 x 3.25 (Grade 5)
36 710-3011 Hex Cap Screw, 3/8-16 x 2.25 (Grade 5)
37 756-0627 Flat Idler Pulley, 3.5 OD
38 754-0472 PTO Belt (42-inch Decks w/ Electric PTO)
754-0474 PTO Belt (46-inch Decks w/ Electric PTO)
Power Take-off System
39 783-0349 Battery Tray
40 783-0891A Deck Stop
41 710-3025 Hex Cap Screw, 5/16-18 x .625
42 736-0105 Bell Washer, .401 x .870 x .063
43 710-0376 Hex Cap Screw, 5/16-18 x 1.0
44 712-3006 Hex Nut, 1/4-20
45 736-0119 Lock Washer, 5/16
46 710-0757 Hex Cap Screw, 7/16-20 x 1.5
47 736-0171 Lock Washer, 7/16
48 750-0956 Spacer
49 756-0982A Engine Pulley
50 712-3004A Flange Lock Nut, 5/16-18
51 747-1204 Belt Guard
52 711-1004 Keeper Pin
53 731-2111 PTO Knob
54 736-0108 Flat Washer, .510 x .750 x .033
55 747-1112A PTO Handle
56 647-0046 PTO Lever
57 710-0528 Hex Cap Screw, 5/16-18 x 1.25
58 732-0995 Extension Spring, .5 x 6.0
59 712-0229 Push Nut, 3/8
60 783-0744A Engagement Stop Bracket
61 748-0415A Spacer, 3/8 x 1.54
62 738-0372 Shoulder Spacer
63 683-0302 PTO Engagement Plate
64 714-0145 Internal Cotter Pin
65 736-0140 Flat Washer, .385 x .62 x .063
66 732-0991 Belt Guard
67 732-0990 Belt Guard
68 732-0994 Extension Spring, .75 x 5.39
69 714-0111 Cotter Pin, 3/32 x 1.0
70 754-0485 PTO Belt (42-inch Decks w/ Manual PTO)
754-0486 PTO Belt (46-inch Decks w/ Manual PTO)
71 710-0615A Hex Cap Screw, 3/8-16 x 5.0
72 736-0277 Flat Washer, 1.031 x 1.62 x .095*
73 736-0322 Flat Washer, .45 x 1.25 x .17*
74 736-0267 Flat Washer. 3/8 x .87 x .06
75 736-0280 Falt Washer, .395 x 1.12 x .10
REF.
NO.
PART
NO. DESCRIPTION
*Found on units equipped with a Kohler engine ONLY.
