MTS Systems 318.25 User Manual

318 Load Unit Safety
43
Base Assembly
ITEM PART NUMBER DESCRIPTION
1
045-384-101 Warning. High force moving parts. Can cause severe injury or
equipment damage.
Stay clear and use eye protection while test is in progress.
Read instructions before operating or servicing.
2
037-588-901 Identification label. Includes model number, part number, serial
number, force capacity, and manufacture date.
3
050-275-301 Information label. No step.
4
050-275-201 Caution. Heavy control panel (up to 15 kg/30 lbs). Can cause
personal injury or equipment damage.
Support control panel until bolts are out. Let down slowly.
5
005-905-101 Warning. If lift cylinder line is opened, air may enter causing
crosshead to drop when unlocked. Bleed both cylinders before
unlocking crosshead.
View A-A
1
1
2
3
4
5
