MTS Exceed™ Series 40 Product Manual
38
Specifications
Introduction
Model E44.104 and E44.304 - Rated Force Capacity 10 kN, 30 kN
85 mm
(3.35 in)
138 mm
(5.43 in)
694 mm
(27.32 in)
Standard height
1862 mm
(73.31 in)
277 mm
(10.91 in)
716 mm
(28.19 in)
845 mm
(33.27 in)
Extended Length
2162 mm
(85.12 in)
