4
Mounting
EDC User's Manual Chapter: 2. Installation
Section: Mounting
Using the dimensions and instructions in the above section of the EDC
User's Manual, mount the Controller. Remember to allow enough space
around the Controller for wiring connections and harnesses.
Connecting DC Power
EDC User's Manual Chapter: 2. Installation
Section: DC Connections
The EDC User's Manual tells you whether you need external power for
• Limits/enables (voltage other than 15 V )
• Servo outputs (if isolation is required, or if maximum voltage
between 10 V and 24 V is required)
• Programmable I/O (if isolation is required, if current greater
than 25 mA is required, or if voltage between 15 V and 24 V
is required)
• Encoders (can be configured for +5 V or + 12 Vdc internal
supply; for 12 V supply, current must be limited to 300 mA
per axis up to 40° C and 200 mA per axis up to 50°C. If
greater currents are required, or if isolation is required, use
an external supply.)
If external dc power is required, connect it as explained in the above
section of the EDC User’s Manual.
