16
S4 is provided as a means to determine the resolution of the simulated encoder signals.
The amplifier is configured form the factory to be 1024 lines.
S4 1 2 3 4 Lines
ON ON ON ON 2000 (14-bit only)
OFF ON ON ON 500
ON OFF ON ON 400
OFF OFF ON ON 1024 (default)
ON ON OFF ON 250
OFF ON OFF ON 1000
ON OFF OFF ON 720
OFF OFF OFF ON 360
OFF OFF OFF OFF 4096 (14-bit only)
The normal factory configuration of 2-Channel quadrature provides for output resolution of
12 bits or 4096 counts per revolution.
The maximum tracking rate of the amplifier is limited by the resolution selection of the R-D
Converter of 12-bit or 14-bit. This also affects the line choices.
