Operating Instructions
Diesel engine
6R 1600 G10F, G20F
6R 1600 G40F, G50F
6R 1600 G70F, G80F
6R 1600 G10S, G20S
6R 1600 G70S, G80S
6R 1600 B30S, B40S
MS15022/03E

Table of Contents

Questions and Answers

  • B
    bradleygonzalesAug 19, 2025
    How to fix an MTU 6R 1600 G80S that won't turn over?
    • J
      Jeremy CaseyAug 19, 2025
      If your MTU Engine doesn't turn over when you try to start it, there could be several reasons. First, the battery might be low or defective, so try charging or replacing it. Also, check the cable connections to ensure they are properly secured. Other potential causes include defective engine wiring or a faulty starter. Perform a visual inspection and check plug-in connections to ensure secure seating of assemblies or connectors.
  • A
    Andrew PrattAug 21, 2025
    Why my MTU 6R 1600 G80S Engine does not reach nominal speed?
    • J
      Jason JordanAug 22, 2025
      If your MTU Engine isn't reaching its nominal speed, it could be due to a clogged easy-change fuel filter, so replace it. Another potential cause is a clogged air filter; in this case, check the signal ring position of the service indicator.
  • J
    Jeffery SchmidtAug 25, 2025
    Why is the exhaust gas black from my MTU 6R 1600 G80S?
    • A
      Amy OrtizAug 25, 2025
      Black exhaust gas from your MTU Engine could be caused by a clogged air filter; check the signal ring position of the service indicator.
  • E
    Erik BowmanAug 27, 2025
    Why is the MTU 6R 1600 G80S Engine speed not steady?
    • H
      Holly Woods MDAug 27, 2025
      An unsteady MTU Engine speed can be caused by a fuel system that is not vented. Make sure to vent the fuel system.
  • S
    shughesAug 28, 2025
    What to do if MTU 6R 1600 G80S Engine fires unevenly?
    • J
      jonestimothyAug 28, 2025
      If your MTU Engine fires unevenly, a possible cause is a fuel system that is not vented. Make sure to vent the fuel system.
  • A
    Allison HoAug 30, 2025
    What causes low charge-air pressure in an MTU Engine?
    • J
      Jacqueline NortonAug 30, 2025
      Low charge-air pressure in your MTU Engine could be due to a clogged air filter. Check the signal ring position of the service indicator.
  • G
    gordon01Sep 1, 2025
    Why is the exhaust gas blue from my MTU Engine?
    • C
      Christopher HallSep 1, 2025
      Blue exhaust gas from your MTU Engine can indicate too much oil in the engine. If this is the case, drain some engine oil.
  • A
    Ashley AdamsSep 3, 2025
    How to solve high charge-air temperature in MTU Engine?
    • J
      Juan HendersonSep 3, 2025
      If the charge-air temperature in your MTU Engine is too high, it could be due to a high air-intake temperature. Check the fans and air supply/ventilation ducts.
  • R
    Rebekah GriffinSep 6, 2025
    Why is the exhaust gas white from my MTU 6R 1600 G80S Engine?
    • J
      Joshua BishopSep 6, 2025
      White exhaust gas from your MTU Engine can occur if the engine is not at operating temperature. Allow the engine to run up to its operating temperature.
  • A
    Amber DiazSep 8, 2025
    How to troubleshoot an MTU 6R 1600 G80S that does not turn when the starter is actuated?
    • J
      jefferyharrisonSep 8, 2025
      If the MTU Engine doesn't turn when the starter is activated, you can try the following: * Charge or replace the battery. Refer to the manufacturer's documentation for guidance. * Check if the cable connections are properly secured. Refer to the manufacturer's documentation for instructions. * Inspect the plug-in connections, refer to page 108. * Perform a visual inspection, refer to the manufacturer's documentation.

Summary

1 Safety

1.1 Important provisions for all products

Details on nameplate identification, general information, correct use, modifications, and spare parts.

1.2 Personnel and organizational requirements

Guidelines for operator responsibilities, training, and personal protective equipment.

1.4 Safety regulations for startup and operation

Rules for safe startup, operation, and emergency procedures.

1.5 Safety regulations for maintenance and repair work

Precautions before, during, and after maintenance and repair activities.

1.6 Fire prevention and environmental protection, fluids and lubricants, auxiliary materials

Safety measures for fire prevention, noise, environmental protection, and fluid handling.

3 Technical Data

3.1 6 R 1600 B30 S 60 Hz engine data, optimized fuel consumption

Technical specifications for the 6R 1600 B30S engine at 60Hz.

3.2 6 R 1600 B30 S 50 Hz engine data, optimized fuel consumption

Technical specifications for the 6R 1600 B30S engine at 50Hz.

3.3 6 R 1600 B40 S 50 Hz engine data, optimized emissions

Emissions-related technical data for the 6R 1600 B40S engine at 50Hz.

3.4 6 R 1600 B40 S 50 Hz engine data, optimized fuel consumption

Fuel consumption data for the 6R 1600 B40S engine at 50Hz.

3.5 6 R 1600 B40 S 60 Hz engine data, optimized emissions

Emissions data for the 6R 1600 B40S engine at 60Hz.

3.6 6 R 1600 B40 S 60 Hz engine data, optimized fuel consumption

3.7 6 R 1600 G10 F, G20 F engine data, optimized fuel consumption

3.8 6 R 1600 G10 F, G20 F engine data, optimized exhaust emissions

3.9 6 R 1600 G10 S, G20 S engine data, EPA stage 3

3.10 6 R 1600 G10 F, G20 F engine data, Nonroad stage III a

3.11 6 R 1600 G40 F, G50 F engine data, optimized fuel consumption

3.12 6 R 1600 G40 F, G50 F engine data, optimized exhaust emissions

3.13 6 R 1600 G40 F, G50 F engine data, Nonroad stage III a

3.14 6 R 1600 G70 F, G80 F engine data, optimized fuel consumption

3.15 6 R 1600 G70 F, G80 F engine data, optimized exhaust emissions

3.16 6 R 1600 G70 S, G80 S engine data, EPA stage 3

3.17 6 R 1600 G70 F, G80 F engine data, Nonroad stage III a

4 Operation

4.1 Putting the engine into operation after extended out-of-service periods (>3 months)

Procedure for restarting an engine after long-term storage.

4.2 Putting the engine into operation after scheduled out-of-service-period

4.3 Engine start in manual operation (trials)

Procedure for starting the engine for testing or trials.

4.4 Safety system - Override

4.5 Operational checks

4.6 Engine stop in manual operation (trials)

4.7 Emergency stop

How to use the emergency stop function on the engine.

5 Maintenance

5.1 Maintenance and servicing

Overview of MTU's preventive maintenance concept and general servicing notes.

5.2 Maintenance task reference table

6 Troubleshooting

6.1 Troubleshooting

Common engine problems and their probable causes and tasks.

7 Task Description

7.1.2 Engine - Test run

Steps for conducting a test run of the engine.

7.2.1 Valve clearance - Check and adjustment

How to check and adjust valve clearance on the engine.

7.3.1 Fuel system - Venting

7.4.1 Fuel filter - Replacement

7.4.2 Fuel prefilter - Replacement

7.5.1 Air filter - Replacement

7.8.1 Engine oil level - Check

Procedure for checking the engine oil level.

7.8.2 Engine oil - Change

Steps for changing the engine oil and oil filter.

7.9.1 Engine oil filter - Replacement

How to replace the engine oil filter element.

7.10.1 Engine coolant - Level check

Procedure for checking the engine coolant level.

7.10.2 Engine coolant - Change

Steps for changing the engine coolant.

7.10.3 Engine coolant - Draining

Procedure for draining the engine coolant.

7.10.4 Engine coolant - Filling

Procedure for filling the engine coolant.

7.11.1 Drive belt - Adjustment

7.11.2 Drive belt - Condition check

7.11.3 Drive belt - Tension check

7.11.4 Drive belt - Replacement

7.12.1 Engine wiring - Check
