MTX MUD65PL User Manual

8 pages

To Next Page

To Previous Page

MTX.COM

Figure 2

RGB Ground

+12V –

2A Fuse (max)

(sold separately)

(17.5cm)

+12V

Color Combinations: Splice and combine the ground wires to yeild a different color.

Red Red

Green Green

Blue Blue

Red / Green Lime Green

Red / Blue Magenta

Green / Blue Aquamarine

Red / Green / Blue Blue-White
