MTZ 1220.3 - Page 155

MTZ 1220.1/1220.3 Section I. Coupling of implements
I9
Tractor: PTO shaft end Machine: PIS bushing
y
y
y
Fig. I-11.
PTO Shank type
Rotational speed, rpm
Transmitted
power, kW (h.p.)
PTO diesel engine
Rear independent
PTO 1с
PTO 1
PTO 2
540
540
1000
2037
2037
2100
60 (80)
60 (80)
80 (120)
Front independent
PTO 2 1000 1845 50 (68)
Rear synchronous
PTO 1с
PTO 1
PTO 2
4,18 rev/1 meter of travel 60 (80)
PTO 1C
(8 splines)
PTO 1
(6 splines)
PTO 2
(21 splines)
