MTZ 1220.1/1220.3 Section D . Operation controls and instruments
D12
Air-conditioner control (if it is in-
stalled instead of fan-heater)
Climatic installation control console has
switches (1) and (2).
1 – Air flow adjustment switch;
2 – Air-conditioner switch and refrigerat-
ing output adjustment.
Indicating lamp block (1)
Fuses
