MTZ 1220.1/1220.3 Section D . Operation controls and instruments
D23
Changing of steering wheel position
To adjust the height of the two-arm
steering wheel, proceed as follows:
• Remove the cover (2);
• Unscrew the clamp (1) for 3…5
turns;
• Set the steering wheel 3 in the re-
quired position;
• Tighten the clamp (1) manually and
fix the cover (2) back.
• Steering wheel height adjustment
range is 100 mm.
To adjust the height of the tree-arm
steering wheel, proceed as follows:
• Unscrew the clamp (1) for 3…5
turns;
• Set the steering wheel 2 in the re-
quired position;
• Tighten the clamp (1) manually
• Steering wheel height adjustment
range is 100 mm.
The steering column can tilt to four dif-
ferent positions from 25° to 40° relative
to horizontal line in increments of 5°).
In order to tilt the steering column, pull
the handle (3) on.
