MTZ 1220.1/1220.3 Section А. Introduction
А3
International Symbols
Manufacturer uses standard international symbols regarding instruments and operat-
ing controls.
Symbols with their meaning are given below.
— see operators manual — control operating direction
— brake — fast
— parking brake — slow
— horn — forward
— alarm signaling — reverse
— fuel level in the tank — battery charging condition
— coolant — cab dome light
— starting preheater plug
— marker lights
— engine speed — turning signals
— engine oil pressure — headlights main beam
— engine coolant temperature
— headlights lower beam
— off/stop — working headlights
— on/start — differential lock
— continuous change — PTO engaged
— lever — down
— FDA engaged
— lever — up — fan
