5
INSTALLATION
Using provided screwdriver, insert Screw A
through the Fire Bowl Air Vent (7) and attach
to the base of the Fire Bowl (6). Secure
screw with provided Nut fastener from the
inside of the Fire Bowl. Do not overtighten to
allow for vent rotation.
STEP 1:
STEP 2:
STEP 3:
Place the Ash Collector (8) over the three
Legs (9) of the grill. Make sure the collector
sits horizontally between the three legs.
Attach the Fire Bowl (6) to the Legs (9) by
aligning legs and inserting 3 x Screw B into
allocated holes from the inside of the Fire
Bowl. Finger tighten the screws to hold each
leg into position before tightening with the
screwdriver. Do not overtighten the legs.
