Multi-Link Stick - Programming and Quick Reference Guide

7
THE STICK PROGRAMMING AND QUICK REFERENCE GUIDE
REGISTER # PROGRAMMABLE
FEATURE
PROGRAM
RANGE
FACTORY
PRESET
PROGRAMMING / INSTALLATION
RECOMMENDATIONS
YOUR
PROGRAM
01
FAX Tone Detection
0 = off
1 = on
ON
Regardless of how you install the Stick, if a FAX/PC
FaxCard is used—Program this feature “ON”
02
Protected Hook
Flash
0 = off
1 = on
OFF
With older KEY and PBX systems, you may need to
program this feature “ON”
03
Unanswered Call
Silent Transfer
0 = off
1 = on
OFF
“UCST” routes all unanswered after-hours calls to
fax or modem ports (on any installation)-—
program "ON”
04
Silent Transfer
Destination
0 = fax
1 = modem
FAX
This feature determines what device will receive a
call after it has been “silently transferred”
05
Pulse Detection
0 = off
1 = on
OFF
If you have pulse-dial phones and wish to transfer
or “grab” a call—program this feature ”ON”
06
Call Override
0 = off
1 = on
OFF
If The Stick is installed at a walljack and you want
to answer a call from any extension phone—
program “ON”
07
Unrestricted Manual
Transfer
0 = off
1 = on
ON
Gives transfer ability at any time, from either party
from any phone, recommended programming
“ON”
08
Answering Machine
Silent Transfer
0 = off
1 = on
OFF
After answering machine times out, call will be
routed to fax or modem port (any installation)—
program “ON”
11
Security Access Code
for VOICE Ports
Digits 0-9 *
and #
4 digits max.
*1
This register contains the code for transfer of a
voice or modem call to devices connected to voice 1
& 2 ports
12
Security Access code
for FAX Port
Digits 0-9 *
and #
4 digits max.
*2
This register contains the code for transfer of a
voice or modem call to FAX/PC FaxCard
CONNECTED to fax port
13
Security access code
for MODEM Port
Digits 0-9 *
and #
4 digits max.
*3
This code is usually sent by calling modem—we
recommend programming a 4 digit code for
security purposes
14
Rings to answer
0 to 10 Rings
0 Rings
If the stick is used on a KSU or PBX set to “0” –
home installs w/ext. phone access, program needed
no. of rings
15
Maximum rings
4 to 30 Rings
8 Rings
This feature controls the number of times a device
(voice, fax, modem) is rung by the stick before
dropping the call
