INPUT POWER REQUIREMENTS-
At AC Transformer:
1
10-125
Volts AC Only, 50-60 Hz
At Power Jack On Stick: 12-14 Volts AC and DC
POWER
CONSUMPTION-
6.2 Watts
CO INTERFACE-
Ringer Equivalence Number: 0.5 B
Input Ring Detection: 40-150 Volts AC, 15-68 Hz
DEVICE INTERFACE-
Battery: -48 Volts Nominal DC To All Devices
Off-Hook Detection: 3-80 mA
Ring Generator Frequency:
30
Hz (+/-
..1)
Hz Voltage Regulated
and Current Limited
Waveform: True Sinusoidal
Ringing No Load: Approx. 82.8 Volts RMS AC
Ringing 8000 Ohm Impedance (REN 1
.0):
Approx. 8 1.6 Volts RMS AC
Ringing 4000 Ohm Impedance (REN 2.0):
Approx. 73.0 Volts RMS AC
Ringing 2667 Ohm Impedance (REN 3.0):
Approx. 64.5 Volts RMS AC
Ringing 2000 Ohm Impedance (REN 4.0):
Approx. 55.0 Volts RMS AC
Ringing 1800 Ohm Impedance (REN 5.0):
Approx. 49.5 Volts RMS AC
29
