Manual for MULTI Winch 3000 & 5000
TREJON AB - 14 - www.trejon.se
3. PREPARATION TO THE WORK
3.1. Before connection to the tractor, check that nobody is standing between tractor and
winch.
3.2. Joint winch to three-point linkage. By means of the screws of hanging mechanism of
tractor, adjust stable position of the winch.
3.3. Connect the cardan shaft:
P=30 kW
n=540 r/min
L=560 mm
3.4. Start the tractor by switching on PTO shaft and being sure that winch is ready for work.
4. WORK
It is recommended to start working with logs or tree-trunks of smaller diameter in the
beginning.
4.1. Support winch to the ground at the working place.
4.2. Mechanism of winch is in initial position (see drawing 4). To bring the winch into
preparatory position (see drawing 5): release band brake 4 by pulling of the string 2 or
pushing switching lever 3 into end position (as far as tooth 11 and 12 are finally locked
to each other). Pull out the cable 10.
4.3. Fix the hooking chain around the log and fasten it to the cable.
4.4. To bring mechanism in initial position (see drawing 4) pull string 1 until locking tooth 11
and 12 are unlocked.
4.5. Pulling the strings 1 and 2 at the same time, haul the logs close to the winch.
4.6. To stop the drum, don’t pull guiding strings 1 and 2 any more.
4.7. Fix the hooking chains into slots that have been located on upper board of the winch.
5. MAINTENANCE
Before cleaning, maintenance and adjustment of the winch, turn off the PTO of tractor
and stop the engine.
5.1. After 4 hours workings check fasteners and tight them, if needed.
5.2. Every day lubricate the chain 9 (see drawing 2) by dropping the oil on links of chain.
Recommended oil is industrial oil for general-purpose with characteristics as follows::
- kinetic viscosity at 50ºC 17-23 mm
2
/sec
- viscosity index 85
- gelosing temperature under ºC -30
- ignition temperature ºC 180
For example: ADDINOL C32 or other analogues.
5.3. After 40 hours working, make following maintenance (look draws 2, 3 and 4):
• Lubricate with consistencial lubrication all lubricating nipples – two on tops of axis
5, one on each block wheel 13 and 14;
• Lubricate with consistencial lubrication driving cable 10, springs 22 and 23 of clutch
and brake, driving chain 9 and locking tooth 11 and 12 of levers of clutch and
brake;
NB! Use lubrications for general-purpose:
- dropping temperature ºC 180
- consistency (fall-cone test) from 265 to 295
• Lubricate the axis of inert brake by dropping oil from the oil- jug into the hole 29;
NB! Use as basic oil – mineral oil
- kinematical viscosity at 40ºC 60+5 m
2
/sec
- ignition temperature ºC 200
- gelosing temperature under ºC -22
For example: ADDINOL CF2 or other analogues.
• Check the condition of cable and hooks.
