Manual for MULTI Winch 3000 & 5000
TREJON AB - 15 - www.trejon.se
5.4. Adjusting the clutch (see draw 3):
- untwist the fixing nuts 15 of the axis;
- turn the axis 5 clockwise (about half turn) by spanner, keeping the position of the axis 5 fix
fastening nuts;
- check the free moving of the clutch pulling from the string 1.
5.5. Adjusting the brake (see draw 2):
- by turning the nut 16 located on the top of the band brake pull the band of brake against the
drum and then tighten nut 17;
- adjust by means of adjusting bolts 18 the distance between the braking girdle 19 and the
inner surface of braking band 20 to be equally 1 mm and then tighten nuts 21.
5.6. Adjusting the driving chain (look draw 2):
- release nuts 26 of the tightening sector 25 of the chain tightener 24;
- tighten the chain with the sector;
- tighten nuts of the sector.
5.7. Adjusting the inert brake (look draw 3):
- untwist nut 28 of the adjusting bolt 27 of inert brake;
- twist the adjusting bolt until inert brake touches the flange of drum 6;
- tighten the nut 28.
5.8. Once in a season make more complete maintenance:
-Demount winch and inspect conditions of all parts and components. Replace defected
parts/components.
