Manual for MULTI Winch 3000 & 5000
TREJON AB - 16 - www.trejon.se
Spare part list MULTI Winch 5000
Draw 1 WINCH 5000
No. Marking Description
1. 075.10.00.000 Rope of coupling collar
2. 075.11.00.000 Coupling rope of clutch
3. 075.13.00.000 Coupling lever of belt brake
13. 075.05.00.000 Upper wire block
14. 075.06.00.000 Lower wire block
