Manual for MULTI Winch 3000 & 5000
TREJON AB - 17 - www.trejon.se
Draw 2 WINCH 5000
Nr. Marking Description
4. 075.01.05.200 Stopping belt
9. 075.01.14.000 Chain
16. 075.01.05.302 Tensor nut
17. Nut M10
18. Bolt M10 x 30
21. Nut M10
22. 075.01.05.006 Spring
23. 075.01.05.006 Spring
24. 075.01.12.000 Chain tightener
25. 075.01.00.005 Disc
26. Nut M10
