Manual for MULTI Winch 3000 & 5000
TREJON AB - 7 - www.trejon.se
Spare part list MULTI Winch 3000
Item Draw Marking Description Quan-
no tity
1 1; 2; 3 030.01.000 Frame 1
2 1; 2; 3 030.02.000 Frame of the drive 1
3 1; 2; 3 030.03.000 Cover of the winch 1
4 2; 3 030.04.000 Barrel 1
5 1; 3 030.05.000 Cover of the barrel 1
6 1; 2 030.06.000 Cable block 1
7 1; 2 030.07.000 Rope block 1
8 1; 2 030.08.000 Rope block of the clutch 1
9 3 030.09.000 Drawn chain wheel 1
10 3 030.10.000 Clutch 1
11 2 030.11.000 Chain stainer 1
12 1; 2 030.12.000 Cable 1
13 1; 2 030.13.000 Movable hook 1
14 1 030.14.000 Loop cable 5
15 1 030.15.000 Stand 2
16 3 030.16.000 Nut with a tip 1
17 1 030.17.000 Locker of the stand 2
19 3 030.00.001 Shaft 1
20 2; 3 030.00.002 Driving shaft 1
21 2; 3 030.00.003 Chain wheel 1
22 3 030.00.004 Slat 1
23 1 030.00.005 Plate 1
24 1; 2 030.00.006 Spring 1
25 1; 2; 3 030.00.007 Finger 2
26 1; 2; 3 030.00.008 Splint 2
27 3 030.00.010 Cover 1
28 2 030.05.400A Bar 1
29 2 11382.04.014 Plate 1
30 2; 3 Nut M24 1
31 2; 3 Nut M16 6
32 2 Nut M12 4
33 2 Nut M10 4
34 2; 3 Screw M16 x 40 6
35 2 Screw M10 x 30 4
36 2 Screw M10 x 20 2
37 3 Screw M 6 x 10 4
38 2; 3 Sheave 24 2
39 2 Sheave 10 4
40 2; 3 Spring sheave 16 6
41 2 Spring sheave 12 4
42 2 Spring sheave 10 2
43 3 Spring sheave 6 4
44 3 Ratchet 1625 1
45 3 Cuff 1 - 50 x 70 1
46 3 Single-line radial ball bearing no 305 2
47 3 Single-line radial supporting ball bearing no 8210 2
48 3 Grease nipple 1.2 4
49 3 Chain P-15, 875-2300-2 with connection
C- P-15, 875-2300-2
1
50 1; 2 Rope 1
51 1; 2 030.03.200 Lever 1
