Parts List Solius KIT # 21 4264
Part No. Description Material Dimensions
No. off
1 1 Building instructions Paper
1.1 1 Complaint form, models Paper
2.1 1 Decal sheet “A” Printed adhesive film 111 x 1000 mm
2.2 1 Decal sheet “B” Printed adhesive film 196 x 1000 mm
2.3 1 Fin sticker White adhesive film 170 x 120 mm
3 1 L.H. fuselage shell Moulded Elapor foam Ready made
4 1 R.H. fuselage shell, with fin Moulded Elapor foam Ready made
5 1 Canopy frame Moulded Elapor foam Ready made
6 1 Tailplane Moulded Elapor foam Ready made
7 1 L.H. wing with spar Moulded Elapor foam Ready made
8 1 R.H. wing with spar Moulded Elapor foam Ready made
9 1 Left fin moulding Moulded Elapor foam Ready made
10 1 Glider nose cone (kit version only) Moulded Elapor foam Ready made
11 1 Clear canopy Inj.-moulded plastic Ready made
12 1 Wheel Plastic 45 mm Ø
Small parts set
20 3 Velcro tape, hook Plastic 25 x 60 mm
21 3 Velcro tape, loop Plastic 25 x 60 mm
22 2 Canopy latch catch Inj.-moulded plastic Ready made
23 2 Canopy latch tongue Inj.-moulded plastic Ready made
25 1 Battery retaining strap Plastic 16 x 200 mm
26 3 “Twin” control surface horn Inj.-moulded plastic Ready made
27 3 Swivel connector barrel Metal Ready made, 6 mm Ø
28 3 Socket-head grubscrew Metal M3 x 3 mm
29 1 Allen key Metal 1.5 A/F
30 2 Aileron pushrod (one Z-bend) Metal 1 Ø x 60 mm
31 1 Rudder pushrod (one Z-bend) Metal 1 Ø x 50 mm
32 1 Elevator pushrod (one L-bend) Metal M2, 1.7 Ø x 121/10 mm
33 1 Clevis Metal M2
34 2 Cable holder Inj.-moulded plastic Ready made
35 2 Plastic tailplane screw Inj.-moulded plastic M5 x 35 mm
36 2 Nut Metal M5
37 4 Screw (wing retaining clip) Metal 2.2 x 6.5 mm
38 1 Machine screw (wheel axle) Metal M3 x 30 mm
39 1 Self-locking nut (wheel axle) Metal M3
40 3 Trim ballast Metal ball 13 mm Ø / 9 g
41 2 O-ring Plastic 8 x 2 mm
42 3 Cable tie Plastic 98 x 2.5 mm
43 2 Spacer sleeve Plastic 3.1 Ø x 6 Ø x 4 mm
Plastic parts set
50 1 Motor bulkhead Inj.-moulded plastic Ready made
51 1 Battery support plate Inj.-moulded plastic 20 x 60 mm
52 1 Wheel frame Inj.-moulded plastic Ready made
53 1 L.H. root rib Inj.-moulded plastic Ready made
54 1 R.H. root rib Inj.-moulded plastic Ready made
55 4 Retaining clip Inj.-moulded plastic Ready made
56 1 Wing locking pin Inj.-moulded plastic Ready made
57 1 Dummy tailwheel Inj.-moulded plastic Ready made
58 1 Tailplane spreader plate Inj.-moulded plastic Ready made
59 1 Tailplane screw support (for nuts) Inj.-moulded plastic Ready made
60 1 Elevator horn Inj.-moulded plastic Ready made
61 1 L.H. servo fairing Inj.-moulded plastic Ready made
62 1 R.H. servo fairing Inj.-moulded plastic Ready made
