Page #9 background image
9
Lfd. Stück Bezeichnung Material Abmessungen
1 1 Bauanleitung Papier 80g/m² DIN-A4
2 „A“ 1 Dekorbogen bedruckte Klebefolie 500 x 750mm
2 „B“ 1 Dekorbogen bedruckte Klebefolie 500 x 750mm
3 1 Rumpf Elapor geschäumt Fertigteil
4 1 Tragäche links Elapor geschäumt Fertigteil
5 1 Tragäche rechts Elapor geschäumt Fertigteil
6 1 Querruder links Elapor geschäumt Fertigteil
7 1 Querruder rechts Elapor geschäumt Fertigteil
8 1 Höhenleitwerk Elapor geschäumt Fertigteil
9 1 Höhenruder Elapor geschäumt Fertigteil
10 1 Seitenruder Elapor geschäumt Fertigteil
11 1 Fahrwerksverkleidung links Elapor geschäumt Fertigteil
12 1 Fahrwerksverkleidung rechts Elapor geschäumt Fertigteil
CFK-Leisten
13 2 Leiste Fahrwerk CFK 10 x 1,5 x 144mm
14 2 Leiste Rumpf CFK 3,0 x 1,0 x 743mm
15 2 Leiste Tragäche CFK 3,0 x 1,0 x 850mm
16 1 Leiste Höhenruder CFK 3,0 x 1,0 x 400mm
17 2 Leiste Rumpf vorne CFK 3,0 x 1,0 x 120mm
18 2 Radachse CFK Ø2,5 x 32mm
Kleinteilesatz
20 2 Klettband Pilzkopf Kunststoff 25 x 60mm
21 2 Klettband Velours Kunststoff 25 x 60mm
22 3 Folienscharnier (6er-Baum) Kunststoff gespritzt Fertigteil
23 4 Einkleberuderhorn Kunststoff gespritzt Fertigteil
24 4 Gestängeanschluß Metall Fertigteil Ø6mm
25 4 U-Scheibe Metall M2
26 4 Mutter Metall M2
27 4 Inbus-Gewindestift Metall M3 x 3mm
28 1 Inbusschlüssel Metall SW 1,5
29 2 Querrudergestänge m.Z. Metall Ø1 x 70mm
30 1 Höhenrudergestänge m.Z. Metall Ø1 x 85mm
31 1 Seitenrudergestänge m.Z. Metall Ø1 x 115mm
32 1 Motorspant Kunststoff gespritzt Fertigteil
33 4 Inbus-Gewindestift Motorspantjustierung Metall M3 x 10mm
34 2 Inbus-Schraube Motorspantbefestigung Metall M3 x 12mm
35 1 Motorspanthalter Kunststoff gespritzt Fertigteil
36 1 Fahrwerkshalter vorne Kunststoff gespritzt Fertigteil
37 1 Fahrwerkshalter hinten Kunststoff gespritzt Fertigteil
38 2 Leichtrad Kunststoff EPP Ø53 Nabe 2,6mm
39 4 Wellensicherung Räder Metall für Ø2 mm
40 1 Achshalter links Kunststoff gespritzt Fertigteil
41 1 Achshalter rechts Kunststoff gespritzt Fertigteil
42 1 Inbusschlüssel Metall SW 2,5
43 2 Schraube Fahrwerkshalter Metall 2,2x6,5mm
D
Stückliste KIT ParkMaster PRO # 21 4275
