Xeno Parts List
Part No. Description Material Dimensions
No. off
1 1 KIT building instructions Paper, 80 g/m² A4
2 1 Decal set Printed adhesive film 700 x 333 mm
3 1 L.H. wing panel Moulded Elapor foam Ready made
4 1 R.H. wing panel Moulded Elapor foam Ready made
5 2 Fin Moulded Elapor foam Ready made
Small items
10 3 Velcro tape, “hook” Plastic 25 x 60 mm
11 3 Velcro tape, “loop” Plastic 25 x 60 mm
12 2 Swivel pushrod connector Metal Ready made, 6 mm Ø
13 2 Washer Metal M2
14 2 Nut Metal M2
15 2 Socket-head grubscrew Metal M3 x 3 mm
16 1 Allen key Metal 1.5 mm A/F
Plastic parts
20 1 L.H. fuselage cradle shell Inj. moulded plastic Ready made
21 1 R.H. fuselage cradle shell Inj. moulded plastic Ready made
22 7 Hinge leaf Inj. moulded plastic Ready made
23 1 Glider canopy Inj. moulded plastic Ready made
24 1 L.H. canopy latch Inj. moulded plastic Ready made
25 1 R.H. canopy latch Inj. moulded plastic Ready made
26 2 Fin holder Inj. moulded plastic Ready made
27 2 Fin retaining clip Inj. moulded plastic Ready made
28 1 L.H. fin support Inj. moulded plastic Ready made
29 1 R.H. fin support Inj. moulded plastic Ready made
30 2 Glue-fitting horn Inj. moulded plastic Ready made
31 1 L.H. servo fairing Inj. moulded plastic Ready made
32 1 R.H. servo fairing Inj. moulded plastic Ready made
Wire and rod
40 2 Pre-formed pushrod, one Z-bend Metal 1.3 Ø x 130 mm
41 1 Hinge wire with L Metal 1.3 Ø x 165 mm
42 2 Wing spar CFRP flat strip 6 x 1.5 x 270 mm
