Examine your kit carefully!
MULTIPLEX model kits are subject to constant quality checks throughout the production process, and we sincerely hope that you are
completely satisfied with the contents of your kit. However, we do ask you to check all the parts (referring to the Parts List) before you
start construction, as we cannot exchange components which you have already modified. If you find any part is not acceptable, we
will readily correct or exchange it once we have examined it. Just send the component, with adequate postage pre-paid, to our Model
Department; please be sure to include the purchase receipt and the returns form (included in the kit) completed in full. We are
constantly working on improving our models, and for this reason we must reserve the right to change the kit contents in terms of
shape or dimensions of parts, technology, materials and fittings, without prior notification. Please understand that we cannot
entertain claims against us if the kit contents do not agree in every respect with the instructions and the illustrations.
Caution!
Radio-controlled models, and especially model aircraft, are by no means playthings. Building and operating them safely
requires a certain level of technical competence and manual skill, together with discipline and a responsible attitude at the
flying field. Errors and carelessness in building and flying the model can result in serious personal injury and damage to
property. Since we, as manufacturers, have no control over the construction, maintenance and operation of our products, we
are obliged to take this opportunity to point out these hazards and to emphasise your personal responsibility.
Additional items required for the “Xeno”:
MULTIPLEX radio control components for the Xeno:
RX-6-SYNTH IPD receiver 35 MHz A / B- band Order No. 5 5876
alternatively: 40 / 41 MHz Order No. 5 5877
or MULTIPLEX RX-7-DR light M-Link 2.4 GHz Order No. 5 5810
Tiny MG servo, two required (2 x elevon) Order No. 6 5122
Battery charger:
MULTIcharger LN-3008 EQU Order No. 9 2540
for LiPo, LiIo and LiFe batteries, 2S to 3S, and
NiMH / NiCd batteries with 4 to 8 cells
Xeno power set Order No. 33 2654
Contents:
Himax 2212-1180 motor, BL-20 S-BEC speed controller, 8 x 5”
folding propeller, taper collet, driver and 35 mm Ø spinner, canopy,
motor fairing, CFRP extension shaft, plastic parts, small items
Xeno TUNING power set Order No. 33 2655
Contents:
Himax 2816-1220 motor, BL-30 S-BEC speed controller, 9 x 6”
folding propeller, taper collet, driver and 35 mm Ø spinner, canopy,
motor fairing, CFRP extension shaft, plastic parts, small items
Flight battery: Li-BATT BX 3/1-950 Order No. 15 7118
Receiver battery, glider version: 4 AA cells, S or W format Not in MPX range
Tools:
Scissors, balsa knife
Note: please remove the illustration pages from the centre of the instructions.
Specification:
Wingspan: 1245 mm
All-up weight, glider, approx.: 550 g
All-up weight, electric, approx.: 650 / 690 g Standard / Tuning
Wing area: 32 dm²
Wing loading min.: 17.2 g/dm² glider, 2.03 g/dm² electric,
21.5 g/dm² electric (Tuning version)
RC functions: Aileron, elevator (delta mixer), throttle
