QP2TH TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #5 (01/29/14) — PAGE 11
Table 1. Specifications (Pump)
Pump
Model QP2TH
Type Trash Pump
Suction 2.0 in. (51 mm.)
Discharge Size 2.0 in. (51 mm.)
Maximum Pumping Capacity
211 gallons/minute
(800 liters/minute)
Max. Solids Diameter 1.00 in. (25.4 mm)
Max. Lift 25 ft. (7.6 m)
Max. Head 98 ft. (30.0 m)
Max. Pressure 42 psi (292 kPa)
Dry Net Weight
97 lbs. (44 Kg.)
SPECIFICATIONS (PUMP)
Figure 1. QP2TH Dimensions
18.8 IN.
17.2 IN.
(437 MM.)
25.3 IN.
(642 MM.)
