QP2TH TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #5 (01/29/14) — PAGE 33
PUMP ASSEMBLY
NO. PART NO. PART NAME QTY. REMARKS
38 0151191257 STUD BOLT, (DRAIN COVER HANDLE) 4
M12 X 57 X15 X 22
39# 0520030310 KEY, 4.7 X21 MM ...................................................1............REPLACES P/N 0520030413
40 43592012400011 IMPELLER WASHER, DIA. 35 X 9 MM T4.5 1
41 0204490060 U-NUT, WEAR PLATE M6 3
42 0205490080 NUT, ENGINE M8 4
43 0205490100 NUT, CUSHION RUBBER M10 8
44 0205490100 NUT, PUMP M10 2
45 0451290100 SPRING WASHER, PUMP M10 2
46 0401650080 WASHER, ENGINE M8 4
47 0457290080 SPRING WASHER, (VOLUTE CASING)M8 2
48 0451290080 SPRING WASHER, (DRAIN COVER SET M8 4
49 0451290100 SPRING WASHER, (CUSHION RUBBER) M10 8
50 0451290080 SPRING WASHER, (ENGINE) M8 4
51# 0458220080 SPRING WASHER, (IMPELLER), M8 ...................1............REPLACES P/N 0451290080
52 0451290080 SPRING WASHER, (CASING COVER ) M8 4
53 0742214050 STRAINER 1
54 1889108050 CAP 1
55 0481310700 O-RING 1
56 1889250770 OVERFLOW SUPPRESSOR 1
57 GX160K1QX2 ENGINE, HONDA 5.5 HP ......................................1............S/N 2TH-3428 AND BELOW
57 GX160U1QX2 ENGINE, HONDA 5.5 HP ......................................1............S/N 2TH-3429 TO 2TH-13438
57 GX160UT2QX2 ENGINE, HONDA 5.5 HP ......................................1............S/N 2TH-13439 AND ABOVE
