RX 1510-C/-I/-CI
– 71 –
Start Stop
FH 4 I00
FH 4200
FH 4300
► Code „FH 4200” is displayed, if no further signal is received from the generator
and from the oil pressure sensor.
► End of the stop procedure. „FH 4300” is displayed. The operating hour meter
is secured. The machine shuts down. Restarting is only possible after the end
of this stop sequence.
Remove the key after finishing work and secure the machine against
unauthorized use.
5.4.2 Switching the machine off with the manual control device
► Press the "Stop" key on the manual control.
► The following code is displayed: „FH 4100”. The LEDS for generator and oil
pressure drop are active. The stop procedure is initiated.
Stop procedure
Start-up
