SP 1 SAW — OPERATION AND PARTS MANUAL — REV. #6 (06/09/08) — PAGE 51
HONDA GX390K1QWT2/GX390U1QWT2 ENG. — CRANKCASE ASSY.
NOTE


 GX390K1QWT2: Model S/N DECEMBER 2005 AND BELOW
◊◊
◊◊
◊ GX390U1QWT2: Model S/N JANUARY 2006 AND ABOVE
CRANKCASE COVER ASSY.
NO. PART NO. PART NAME QTY. REMARKS
2


 11300ZE3602 COVER ASSY., CRANKCASE .........................1 ................ S/N 3287256 AND BELOW
............................................................................................ INCLUDES ITEMS W/>
2



11300ZE3604 COVER ASSY., CRANKCASE .........................1 ................ S/N 3287257 AND ABOVE
............................................................................................ INCLUDES ITEMS W/
%
2
◊◊
◊◊
◊
11300ZE3604 COVER ASSY., CRANKCASE .........................1 ................ INCLUDES ITEMS W/$
3 11381ZE3801 GASKET, CASE COVER 1
4 15600ZG4003 CAP ASSY., OIL FILLER .................................1 ................ INCLUDES ITEM W/
#
5 15600735003 CAP ASSY., OIL FILLER .................................1 ................ INCLUDES ITEM W/
*
8#
*
15625ZE1003 GASKET, OIL FILLER CAP 2
9 16510ZE3000 GOVERNOR ASSY. ..........................................1 ................ INCLUDES ITEMS W/+
10>%$+ 16511ZE8000 WEIGHT, GOVERNOR 3
11
>%$+ 16512ZE3000 HOLDER, GOVERNOR WEIGHT 1
12>%$+ 16513ZE2000 PIN, GOVERNOR WEIGHT 3
13


 >$% 16531ZE2000 SLIDER, GOVERNOR ......................................1 ................ S/N 3287256 AND BELOW
13


 >%$ 16531Z0A000 SLIDER, GOVERNOR ......................................1 ................ S/N 3287257 AND ABOVE
13
◊◊
◊◊
◊ >%$ 16531Z0A000 SLIDER, GOVERNOR 1
15>%$ 90602ZE1000 CLIP, GOVERNOR HOLDER 1
16 90701HC4000 PIN, DOWEL (8X12) 2
17>%$ 91201ZE3004 OIL SEAL (35X52X8) 1
18>%$ 9410106800 WASHER, PLAIN (6MM) 1
19 957010804000 BOLT, FLANGE (8X40) 7
20>%$ 961006202000 BEARING, RADIAL BALL (6202) 1
21>%$ 961006207000 BEARING, RADIAL BALL (6207) 1
