SP 1 SAW — OPERATION AND PARTS MANUAL — REV. #6 (06/09/08) — PAGE 57
HONDA GX390K1QWT2/GX390U1QWT2 ENG. — CYLINDER HEAD ASSY.
NOTE
GX390K1QWT2: Model S/N DECEMBER 2005 AND BELOW
◊◊
◊◊
◊
GX390U1QWT2: Model S/N JANUARY 2006 AND ABOVE
CYLINDER HEAD ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1
12200ZF6W01 CYLINDER HEAD .............................................1 ................ INCLUDES ITEMS W/
*
1
◊◊
◊◊
◊
12200ZF6406 CYLINDER HEAD .............................................1 ................ INCLUDES ITEMS W/%
2
*
% 12204ZE2306 GUIDE, VALVE (OS) (OPTIONAL) 1
3
*
% 12205ZE2305 GUIDE, EX. VALVE (OS) (OPTIONAL) 1
4
*
% 12216ZE2300 CLIP, VALVE GUIDE 1
5 12251ZF6W00 GASKET, CYLINDER HEAD 1
6 12310ZE3791 COVER, HEAD 1
7 12315ZE3840 TUBE, BREATHER 1
8 12391ZE2020 GASKET, CYLINDER HEAD COVER 1
10 17316611000 CLIP, BREATHER TUBE 2
11 90014ZE2000 BOLT, HEAD COVER 1
12 90042ZE8000 BOLT, STUD (8X131.5) 2
13 92900080320E BOLT 2, STUD (8X32) 2
14 90441ZE2010 WASHER, HEAD COVER 1
16 9430112200 PIN A, DOWEL (12X20) 2
17
957251008000 BOLT, FLANGE (10X80) 4
17
◊◊
◊◊
◊
957251008000 BOLT, FLANGE (10X80) ...................................4 ................ S/N 1411816 AND BELOW
17
◊◊
◊◊
◊
957011008000 BOLT, FLANGE (10X80) ...................................4 ................ S/N 1411817 AND ABOVE
18 9807955846 SPARK PLUG (BPR5ES) (NGK) (OPT.) 1
18 9807955855 SPARK PLUG (W16EPR-U) (DENSO) 1
18 9807956846 SPARK PLUG (BPR6ES) (NGK) 1
18 9807956855 SPARK PLUG (W20EPR-U) (DENSO) 1
To Next Page
