SP 1 SAW — OPERATION AND PARTS MANUAL — REV. #6 (06/09/08) — PAGE 61
HONDA GX390K1QWT2/GX390U1QWT2 ENG. — FLYWHEEL ASSY.
NOTE
GX390K1QWT2: Model S/N DECEMBER 2005 AND BELOW
◊◊
◊◊
◊
GX390U1QWT2: Model S/N JANUARY 2006 AND ABOVE
FLYWHEEL ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 19511ZE3000 FAN, COOLING 1
3 28450ZE3W11 PULLEY, STARTER (SCREEN GRID) 1
7 31100ZE3701 FLYWHEEL 1
10
90201ZE3V00 NUT, SPECIAL (16MM) (1) 1
10
◊◊
◊◊
◊
90201ZE3V00 NUT, SPECIAL (16MM) (1) ........................... 1 ..............S/N 1317976 AND BELOW
10
◊◊
◊◊
◊
90201ZE3790 NUT, SPECIAL (16MM) (1) ........................... 1 .............. S/N 1317977 AND ABOVE
11 90741ZE2000 KEY, SPECIAL WOODRUFF (25X18) 1
To Next Page
