SP 1 SAW — OPERATION AND PARTS MANUAL — REV. #6 (06/09/08) — PAGE 65
HONDA GX390K1QWT2/GX390U1QWT2 ENG. — IGNITION COIL ASSY.
NOTE
GX390K1QWT2: Model S/N DECEMBER 2005 AND BELOW
◊◊
◊◊
◊
GX390U1QWT2: Model S/N JANUARY 2006 AND ABOVE
IGNITION COIL ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1
30500ZF6W02 COIL ASSY., IGNITION 1
1
◊◊
◊◊
◊
30500ZF6W02 COIL ASSY., IGNITION..................................... 1.......... S/N 1411816 AND BELOW
1
◊◊
◊◊
◊
30500ZF6W03 COIL ASSY., IGNITION..................................... 1.......... S/N 1411817 AND ABOVE
2 30700ZE1013 CAP ASSY., NOISE SUPPRESSOR 1
8 31512ZE2000 GROMMET, WIRE 1
12 36101ZE2701 WIRE, STOP SWITCH (430MM) 1
17 90015883000 BOLT, FLANGE (6X28) 2
18 90684ZA0601 CLIP, WIRE HARNESS 1
