SP 1 SAW — OPERATION AND PARTS MANUAL — REV. #6 (06/09/08) — PAGE 73
HONDA GX390K1QWT2/GX390U1QWT2 ENG. — LABELS ASSY.
NOTE
GX390K1QWT2: Model S/N DECEMBER 2005 AND BELOW
◊◊
◊◊
◊
GX390U1QWT2: Model S/N JANUARY 2006 AND ABOVE
LABELS ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1
87522ZH9010 LABEL, CAUTION(ENGLISH ETC.) 1
1
◊◊
◊◊
◊
87516ZH7000 MARK OPERATOR CAUTION 1
1
◊◊
◊◊
◊
87516ZH7810 MARK OPERATOR PICTOGRAPH (OPTION) 1
2
87521ZF6W02 EMBLEM (GX390 HONDA 13.0) 1
2
◊◊
◊◊
◊
87521ZF6W03 EMBLEM (GX390 HONDA 13.0) ............................ 1 ............ S/N 1398206 AND BELOW
2
◊◊
◊◊
◊
87521ZF6W04 EMBLEM (GX390 HONDA 13.0) ............................ 1 ............ S/N 1398207 AND ABOVE
3
◊◊
◊◊
◊
87532ZH7000 MARK, THROTTLE INDICATION 1
4 87534ZE1841 LABEL, AIR CLEANER CAUTION 1
5
◊◊
◊◊
◊
87535ZE1841 MARK, AIR CLEANER SALES POINT 1
6
87532ZH8810 MARK, OIL ALERT (E) 1
7
87528ZE2810 MARK, CHOKE (EXTERNAL) 1
