MULTISPAN UTC-4201A Operating Manual

Off-set correction
Output Scaling
Low Percentage
High Percentage
Mode Selection
-20.0°C to +20.0°C
-20°C to +20°C
Forward /Reverse Sele.
00 to high percentage
Low percentage to 100
Auto/Manual
CT 4 sec to 99 sec
IC 0.000 to 9.999
MR
Hysteresis
-9.0 to +9.0
0.1°C to 50.0°C
-9 to +9
1°C to 50°C
DC 0 to 9999
PC
Sr.
1
2
3
4
5
6
7
8
9
10
11
00.00 to 99.99
Parameter Range for PT.1 sensor
Range for J, K, PT100
Product improvement and upgrade is a constant procedure. So for more updated operating information and support, please
contact our Helpline : 9978991474/75 or Email at marketing@multispanindia.com
www.multispanindia.com
Page - 4
FACTORY SETTING
FACTORY SETTING
PARAMETER
IC
Output scaling
Forward
000%
100%
Auto
CT
High (%)
OFFSET
Mode
PC
DC
Low (%)
MR
VALUES
0.225
6 sec
05.00
25
0°C
0°C
SR.
2
7
4
9
6
10
1
3
8
5
Process Value
Set Value
Factory Setting
Press + key for 3 sec
1) Connection Diagram with Relay Output.:
N
L
C
-
+
Relay
NO
O/P
NC
