Munro LP150B - Pump Specifications and Wiring; LP Series 3;4-3 HP Specifications; LP1502 Specifications; LP3005 Specifications

HP Type Volts/Amps Hz RPM
Motor Voltage
(Factory)
Connected
Service Factor Motor Amps
Max
Liquid
Temperature
Single Phase Three Phase
115V 208V 230V 208V 230V 460V
3/4
Single
Phase
115/208-230
60 3450 230V
11.6 5.8 5.8
180˚F
1 16.6 8.5 8.3
1-1/2 23 12.5 11.5
2
230
-- 13 12
3 -- -- 17
3/4
Three
Phase
208-230/460 60 3450 230V -- -- --
2.6 2.8 1.4
180˚F
1 3.4 3.6 1.8
1-1/2 5.4 5.2 2.6
2 6.8 6.6 3.3
3 10 9.2 4.6
Motor info subject to change without notice, please consult motor nameplate.
HP Type Volts/Amps Hz RPM
Motor Voltage
(Factory)
Connected
Service Factor Motor Amps
Max
Liquid
Temperature
Single Phase Three Phase
115V 208V 230V 208V 230V 460V
2 Single Phase 230 60 3450 230V -- 15.7 16 -- -- -- 180˚F
2 Three Phase 60 3450 -- 8.75 4.35 180˚F
Motor info subject to change without notice, please consult motor nameplate.
HP Type Volts/Amps Hz RPM
Motor Voltage
(Factory)
Connected
Service Factor Motor Amps
Max
Liquid
Temperature
Single Phase Three Phase
115V 208V 230V 208V 230V 460V
5 Single Phase 230 60 3450 230V -- 24 22 -- -- -- 180˚F
5 Three Phase 230/460 60 3450 -- -- -- -- -- 14 7 180˚F
Motor info subject to change without notice, please consult motor nameplate.
PUMP SPECIFICATIONS
LP Series 3/4 HP - 3 HP
LP1502
LP3005
WIRING SIZE CHART
Page 4
Motor
Rating
Circuit
Size
Fuse
Size
Full
Load
Amps
Copper Wire Size
Volts HP Phase KW 12 10 8 6 4 2
120
(1ø)
1/4
1
20
10
5.8
0.186
291
464
692
1171
1863
2350
1/3
1
20
10
7.2
0.246
230
365
546
924
1471
2338
1/2
1
20
15
9.8
0.373
171
272
407
689
1096
1742
3/4
1
20
15
13.8
0.559
130
207
310
524
834
1326
1
1
20
20
16
0.746
99
157
236
399
635
1009
1-1/2
1
30
25
20
1.12
128
192
325
515
822
240
(1ø)
1/4
1
20
5
2.9
0.186
1166
1853
2769
4685
7453
11850
1/3
1
20
5
3.6
0.246
920
1462
2186
3699
5884
9355
1/2
1
20
8
4.9
0.373
685
1090
1629
2756
4384
6970
3/4
1
20
8
6.9
0.559
522
829
1240
2098
3337
5305
1
1
20
10
8
0.746
397
631
944
1597
2540
4039
1-1/2
1
20
15
10
1.12
269
427
639
1081
1720
2734
2
1
20
20
12
1.49
259
411
615
1041
1656
2633
2-1/2
1
30
20
11.6
1.9
220
344
522
885
1407
2238
3
1
30
25
17
2.24
184
292
437
739
1176
1871
5
1
40
30
28
3.73
198
296
502
798
1269
Motor
Rating
Circuit
Size
Fuse
Size
Full
Load
Amps
Copper Wire Size
Volts HP Phase KW 12 10 8 6 4 2
208
(3ø)
1-1/2
3
20
10
6.6
1.12
530
843
1340
2131
3389
5385
2
3
20
15
7.5
1.49
407
648
1031
1639
2607
4145
2-1/2
3
20
15
9.0
1.9
346
551
876
1393
2216
3523
3
3
20
15
10.6
2.24
289
459
731
1162
1849
2939
5
3
30
25
16.7
3.73
181
289
459
730
1162
1847
240
(3ø)
1-1/2
3
20
10
6
1.12
641
1019
1522
2576
4098
6516
2
3
20
10
6.8
1.49
492
783
1170
1979
3148
5006
2-1/2
3
20
15
8.2
1.9
418
666
995
1682
2676
4255
3
3
20
15
9.6
2.24
354
563
841
1423
2264
3600
5
3
30
20
15.2
3.73
243
386
577
977
1555
2472
480
(3ø)
1-1/2
3
20
5
3
1.12
2693
4280
6396
2
3
20
5
3.4
1.49
2019
3210
4797
8116
2-1/2
3
20
10
4.0
1.9
1716
2729
4077
6899
3
3
20
10
4.8
2.24
1615
2568
3837
6492
10328
5
3
20
10
7.6
3.73
973
1547
2311
3911
6221
9891
Values are for estimating purposes only and may not meet NEC code. Design should be veried.
