PARTS BREAKDOWN
ITEM SINGLE
PHASE
HORSEPOWER 3/4 1 1 1/2 2 3
MODEL NO. LP075B LP100B LP150B LP200B LP300B
DESCRIPTION PART NO.
1
▲
Motor, Nema J - 1 Phase
Motor Access Cover
Screw, Access Cover
MLP119370 MLP119399 MLP119219 MLP26452 MLP26453
2
▲
3
4
Mounting Ring
Hex hd. cap screws 3/8 x 3/4”
Square Cut Gasket
Seal, Rotary w/Spring
MLP1300
MLPB909
MLPG001
SCC800
1
4
1
1
1
4
1
1
1
4
1
1
1
4
1
1
1
4
1
1
5
6
▲
7
Impeller, Brass “B” Models
Diffuser
Hex HD. Cap Screws 1/4 x 1 1/4”
Rubber Diffuser Gasket
MLP1201
MLPB903
MLPG002
MLP1407
1
2
1
MLP1410
1
2
1
MLP1415
1
2
1
MLP1420
1
2
1
MLP1430
1
2
1
8
▲
Pump Body
Hex HD. Cap Screws 7/16 x 1”
MLP1100
MLPB912
1
4
1
4
1
4
1
4
1
4
9
▲
▲
10
▲
Base - 48 Y-Frame Motor
Base - 56 J-Frame Motor
Hex HD. Cap Screws 3/8 x 1/2”
Drain Valve 1/4” NPT
3/4” Priming Plug
1/4” Sensor Port
MLP1548
MLP1556
MLPB907
MLP913
•
•
1
--
2
2
2
1
1
--
2
2
2
1
1
--
2
2
2
1
--
1
2
2
2
1
--
1
1
2
2
1
(•) Standard hardware Item ---- (▲) Not Shown
Items SINGLE PHASE HORSEPOWER 2
MODEL NO. LP1502B
DESCRIPTION PART NO.
1
▲
Motor, Nema J - 1 Phase
Motor Access Cover
Screw, Access Cover
MLP33344 1
2
▲
3
4
5
Mounting Ring
Hex HD. Cap Screws 3/8 x 3/4”
Gasket, Square Cut
Seal, Rotary W/Spring
Impeller, Brass “B” Models
MLP2300
MLPB909
MLPG003
PACSC309
MLP2402
1
4
1
1
1
6
▲
7
8
Diffuser
Hex HD. Cap Screws 1/4 x 1 1/4”
Diffuser Gasket
Pump Body
MLP2200
MLPB903
MLPG004
MLP2100
1
2
1
1
▲
9
Hex HD. Cap Screws 7/16 x 1”
Base
MLPB912
MLP2500
4
1
▲
▲
10
▲
Hex HD. Cap Screws 3/8 x 1/2”
Drain Valve 1/4” NPT
3/4” Priming Plug
1/4” Sensor Port
MLPB907
MLP913
•
•
2
2
2
1
(•) Standard hardware Item ---- (▲) Not Shown
LP Series 3/4 HP - 3 HP
LP1502
Page 6
