23
Fix it to the bottom and top panels by means of qty. 6
metal clips and qty. 6 screws (ref.8.6/Optional kits).
The metal clips must be fixed in the position as in the
picture.
Fix it by using a pneumatic screwdriver (ref.3/
Assembling tools).
Assembling guidelinesChapter3
