Syphon
Nozzle
vs.
Standard
Nozzle
STANDARD NOZZLE
Pressurized FUEL Inlets
Turbulence Chamber
SYPHON NOZZLE
Tangential Channels
Pressurized FUEL Inlets
Nozzle Orifice
Pressurized AIR Inlets
Turbulence Chamber
Tangential Channels
Fuel Inlet
Pressurized AIR Inlets
Nozzle Orifice
Fuel Inlet
