9
Features and Controls
NOTE: Illustrations and pictorials begin on page 1.
Location of Controls (Figure 8)
Blade Rotation Control (A) — Use the blade rotation control
to start and stop the rotation of the blade.
Clutch/Brake Pedal (B) — The pedal has two functions. The
first function is a clutch. The second function is a brake.
Headlight Switch (C) — The headlight switch is the first
part of the ignition switch. To use the lights with the engine
running, turn the key to the position for the lights.
Ignition Switch (C) — Use the ignition switch to start and
stop the engine.
Shift Lever (D) — Use the shift lever to change the speed of
the unit.
Lift Lever (E) — Use the lift lever to change the height of
cut.
Parking Brake Lever (F) — Use the parking brake lever to
engage the brake when you leave the unit.
Throttle Control Lever (G) — Use the throttle control lever
to increase or decrease the speed of the engine.
Attachments
This unit can use many different attachments. This unit
can pull attachments like a lawn sweeper, a lawn aerator,
or a hopper spreader. This unit can not use attachments
that engage the ground like a plough, a disk harrow, or a
cultivator.
For trailer and pull-behind attachments, the maximum weight
is 113 kg (250 lbs).
