13 Technical information
mp-PM A3 plotter specification
Type of plotter: Flatbed plotter
Maximum plotting area: 422 mm x 305 mm
Plotting speed with pen: Max. 40 mm/s
Plotter pen: Special plotter pens with
HP fixing
Port: USB Level 2.0
Control language: Based on HP-GL 7475A
Buffer: 16 MB
Drive: Two-phase step motor
Pen station 4 pen holders with double seal
Addressable resolution: 0.01 mm
Repeat accuracy: 0.05 mm
Power supply: Separate power supply with
exchangeable mains power
connection
Power supply input voltage: 100-240 V AC / 50-60 Hz
Power supply input current: 0.7 A max.
Power supply output voltage: 24 V DC
Power supply output current: 1.25 A max.
Environmental conditions: In use: 10° C - 35° C
35% - 75% relative humidity
Storage: -10° C up to 50° C
10% - 90% relative humidity
Safety certificate: EN 60950-1
Interference safety compliance: EN 55022 B
EN 61000-4-2 up to 6
Dimensions: 690 mm x 480 mm x 155 mm
Weight: 8.3 kg
