2cablesof1.5mwithSpeakonde4pins


-Speakerenclosures:2DP-SB1
 2DP-SB2
   2DP-H

-Wiring:Thetwo15mcableswith8-pinSpeakonsdirectlyconnecttherack
with the 2DP-SB1 enclosures. The two 1,5m cables with 8-pin Speakonsare
usedtoconnecttheoutputofbothDP-SB1tobothDP-SB2.Finally,thetwo
1,5mcableswith4-pinSpeakonsareusedtoconnecttheoutputofbothDP-
SB2totheinputsofbothDP-H.

ATTENTION: In order for the speakers to receive their signal, Speakon®
connectorsmustbelocked,turningthemclockwiseuntilthelockingdevice
snapsin.

Auxiliary elements, such as effects, equalisers, mixing consoles, etc.
arenotdeliveredwiththisliveequipment.

Toexpandthesystemtodoubleitspower,Musicsonwilldeliveraflight
case containing solely a Musicson HE-1202 power amplifier, which will be
connected to the signal outputs of the main rack, including the ISP-1014
signalprocessors.










Themod.DP-Henclosureswillbeconnectedinparallelonbothchannels,
whereasthepoweramplificationrackwillpowerthebasssystemsDP-SB1and
Dp-SB2frombothchannels,asshownonthefollowingdiagram:



