MUSICSON DP SYSTEMS - Sub218 Bs Enclosure


9




TECHNICALSPECIFICATIONS

-SPL(1W/1m)............105dB
-Max.SPL(Cont.).........137dB
-RMSPower................1000W
-Impedance................4Ohm
-Frequencyresponse.......65-220Hz(conISP-1014)







RESPONSEOFTHEDP-G(WITHISP-1014)











1.2.2.-SUB-218BSENGLOSURE


Thisenclosureactsasasubbassreinforcementsystem,usedwiththeDP-
4 sound system. It is built as a reflex box, using two identical 18”
speakers. Its inside and the measures and shape of the vents have been
