34
 



Theanglebetweentheenclosurescanbevariedthroughvaluesfrom0to
15degrees,bychangingthepositionofthepinsandthestuds,asshownon
thefigurebelow:


 
0DEGREES15DEGREES



ThecablesandflyingaccessoriesatthefrontoftheenclosuresDP-Hand
DP-Gallowtheusertovarytheangleinstepsof3degrees.

Below you can seeaseriesoffigures that showindetailthe relation
betweentheseelementsandtheenclosure’spositions.








