12
electric current measurement
Ac current and AC current frequency measurement
Press the clamp, open the clamp mouth and clamp one of the
wires under test.
When the measured signal is greater than 0.2a, the meter display
displays the current value and frequency value
of the measured conductor.
(Note: The meter can display the
frequency value only when the current
value is greater than 35A)
Dc current measurement
Press the clamp, open the clamp mouth and clamp one of the
wires under test.
When the measured signal is
greater than 0.2a, the meter display
displays the current value and
frequency value of the measured
conductor.
(Test instrument with dc current function)
