15
In that application example the REF10 NANO acts as master clock for the MC3+ USB. But this time not for improving the unit's
audiophile re-clocking capabilities, but for enhancing its Word Clock generation in two ways:
•
Lowering the jitter of the generated Word Clock signals
•
Increasing the unit's clock accuracy
The MC3+ USB now works as Word Clock master clock for the audio mixer supplying a Word Clock signal not only of lowest jitter,
but also with highest timing accuracy.
In this application, the audio clock rate is determined by the MC3+ USB, setting the master clock rate for the mixer, who then
supplies the master clock for the whole music mix.
COMPUTER
SPEAKER
Analog/Digital USB Audio
Analog
10 MHz Clock
Word Clock
LIVE
MIXER
