J Rear wheel disassembling
CAUTION
If you have the rear wheel tyre
replaced by a tyre-dealer, make
sure that the following tools are
used in the rear wheel disassem-
bling and reassembling:
• 55 mm polygonal socket wrench
• Torque wrench
If the above mentioned operations
are performed with tools other than
those indicated, the rear wheel
parts can be seriously damaged.
Therefore, we strongly recommend
not to have the tyres replaced by
an improperly equipped workshop.
Always have the tyres replaced by
an authorized MV Agusta dealer.
- 32 -
Wheel pin with M50x1.5 mm
left-hand pitch tread
Polygonal nut
55 mm polygonal socket wrench
Torque wrench
