3 Assembly instructions

1. Remove all parts from inside cabinet including oor grate from bottom of crate, underneath cardboard.

2. Remove all parts from inside cabinet.

3. Place cabinet on its top.

4. Attach legs using four 1/4 x 1/2” bolts.

a. Front leg has name plate.

b. Rear legs will also take 2 self tapping screws

5. Put cabinet upright on legs.

6. Place foot pedal between front legs.

7. Attach doors with nuts

8. Loosen bolts on door catches and move out to full extent and tighten bolts. Moving them in slightly will tighten door seal.

9. Place glass on top of cabinet.

10. Place light xture on glass with light switch to the right. Fasten with four 1/4 x 3/4” bolts and at washers.

11. Dust collector

a. Attach body of dust collector to rear panel (right side) with 1/4 x 3/4 bolts and at washers.

b. Place top of dust collector (motor and lter) into top of unit and do up 2 catches.

c. Remove inlet box that covers the dust collector pipe inside the cabinet and place a bead of caulking around the pipe to

seal it. Put inlet box back in place.

12. Tighten all bolts, nuts and screws

13. Place oor grate with cut out corner to the front right of the cabinet. Bring hoses through opening.

14. Plug dust collector into female plug coming from light, then plug male cord from light into 115 V /60 Hz supply. Turn on

switch on vacuum, the switch on the cabinet will turn on light and vacuum or dust collector.

4 Connection of air supply

1. Take out the self-locking connector from the inner package. Wrap a sealing tape around the connector thread. Screw it into

the air inlet hole on the rear side of the electric control box and tighten.

2. Push the coupler of the self-locking connector toward the air inlet hole, the cone-shaped end of the connector will

immediately pop out. Fit it into the air hose connecting to the air compressor. Fasten with a clamp. Push the coupler again

and t in the opposite side of the cone-shaped end. Release and the connection is secured.

5 Installation of xed gun

1. Remove the suction head from the xed gun. Fit in an air jet. Reconnect the suction head and tighten. Loosen the M6 screw

on the gun side and install the corresponding nozzle. Tighten the screw.

2. Connect the side branch of the gun with a suction hose and connect the rear inlet of the gun to the exible metal pipe in

the cabinet. Screw until secured.

3. Connect the other end of the suction hose tot corresponding suction pipe.

6 Installation of movable gun

1. Connect one end of the high pressure air hose to the air connector on the right side of the electric control box, the other

end to the air inlet of the movable gun. Tighten with clamps.

2. Connect one end of the suction hose tot de side branch of the movable gun, the other end to the xed suction pipe.

3. Installation of air jet and nozzle are the same as for the xed gun.

4. Put the movable gun on the mesh screen
