ERROR MESSAGES
If an abnormality arises, the induction hob will enter the protection state
automatically and display the corresponding error codes:
Message
Description
Solution
E 1 / E 2
Protection against under voltage (<85
V) or over voltage (> 285 V)
If the voltage at the mains outlet is lower or
higher than specified, consult a qualified
electrician.
E 3
Induction coil temperature sensor
fault.
Contact the closest MX ONDA Official
Technical Service.
E 4
IGBT temperature sensor failure
Contact the closest MX ONDA Official
Technical Service.
E 5
High temperature (> 280 ºC) of the
induction coil temperature sensor.
Turn off the induction hob and wait for it to
cool down.
E 6
High temperature at IGBT sensor
Check that the ventilation is correct and the
fans are not obstructed.
E r
Internal fault of the control circuits.
Contact the closest MX ONDA Official
Technical Service.
r
There is excess liquid on the buttons
on the control panel
Clean and dry the control panel
INSTALLATION
Drill a hole in the worktop based on the following suggestions:
It must leave at least a
minimum of 5 cm around the
hole, free of obstacles
(furniture, electrical appliances,
etc.).
The thickness of the worktop is
at least 30 mm.
Choose the material of the
worktop that is heat resistant to
avoid deformation caused by
heat radiation from the
induction hob.
A(mm)
B(mm)
C(mm)
D(mm)
E(mm)
F(mm)
275
490
50mm
50 mm
50 mm
50 mm
Under any circumstances, make sure that the induction hob is well ventilated
and that the air inlets and outlets are not blocked.
