INSTALLATION
Drill a hole in the worktop based on the following suggestions:
It must leave at least a minimum of 5 cm around the hole, free of obstacles
(furniture, appliances, etc.).
The thickness of the worktop is at least 30 mm.
Choose the material of the worktop that is heat resistant to avoid
deformation caused by heat radiation from the induction hob.
Under all circumstances, make sure that the induction hob is well ventilated
and that the air inlet and outlet are not blocked.
Make sure the induction hob is in good working order. As shown below
Note: The safety distance between the induction hob and the
cabinet or extractor hood above the induction hob must be at least
760 mm.
